Storage Container Portable Storage Series Liquid Nitrogen Tanks

1. High strength, light weight, small size aluminum structure
2. Ultra-low evaporation loss
3. Number coding for canister place
4. Lockable lid is optional to prevent unauthorized open
5. CE certified
6. Five years vacuum warranty

Send Inquiry Chat Now

Download

Description

product-476-320

The portable series is an economical and practical small liquid nitrogen tank designed specifically for

biological samples that require frequent moving. Small size, light weight, high-strength light weight

aluminum alloy and multi-layer insulation to make sure the safety, light weight and efficient, and it has a

variety of accessories optional.

Features：

◆ High strength, light weight, small size aluminum structure

◆ Ultra-low evaporation loss

◆ Number coding for canister place

◆ Lockable lid is optional to prevent unauthorized open

◆ CE certified

◆ Five years vacuum warranty

Order Information-Parameter List

Cat#		CKS-P302Z030	CKS-P302Z035	CKS-P603Z050	CKS-P606Z050	CKS-P610Z050
Unit Parameter
LN2 capacity (L)		2	2	3	6	10
Neck opening (mm)		30	35	50	50	50
Static evaporation rate(L/ Day)		0.07	0.08	0.12	0.12	0.12
Static holding time (Day)		28	24	26	52	86
Storage capacity
Canister outer diameter (mm)		19	25	38	38	38
Canister height(mm)		120	120	120	120	120
Number of canisters (ea)		3	3	6	6	6
Straw holding capacity (singlelayer)	0.5ml (ea)	90	165	792	792	792
Straw holding capacity (singlelayer)	0.25ml (ea)	204	330	1788	1788	1788
Straw holding capacity (double layers)	0.5ml (ea)	-	-	-	-	-
Straw holding capacity (double layers)	0.25ml (ea)	-	-	-	-	-
Containers
Height(mm)		399	428	435	482	552
Outer diameter(mm)		223	204	223	300	300
Empty weight(kg)		2.8	2.6	3.1	4.8	6.1
Accessories Included
Lockable lid		√	√	√	√	√
Protective PU bag		√	-	√	√	√
