Touch Screen PH/Conductivity Meter

·7-inch colored capacitive touch screen with high resolution(1024*600) and high sensitivity
· Built-in microprocessor chip has Intelligent functions

Description

Touch Screen PH/Conductivity Meter
7-inch colored capacitive touch screen with high resolution(1024*600) and high sensitivity
Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
Auto recognition of 25 buffers with three kinds of options: Europe & USA NIST and China
Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China
It supports PC connection. Wireless bluetooth printing and real-time data transfer to mobile phone are optional
Smart electrode status display to ensure accurate use
Can store 1000 sets of test data, which can be saved and transferred

Conductivity Meter

Technical Parameter	Cat#	01-MP811X	01-MP813X
PH	Measuring range	(-2.00 ~ 20.00)pH	(-1.999 ~ 19.999)pH
	Resolution	0.1/0.01 pH	0.1/0.01/0.001 pH
	Accuracy	±0.02pH	Electrode: ±0.002 pH, Meter: ±0.01 pH
	Auto calibration	1, 2, 3 point
	Buffer	Europe & USA, NIST, China standards
	Input current	≤1×10-12 A
	Input impedance	≥3×1012Ω
	Stability	±0.01 pH/3h	±0.002 pH/3h
	Temp.compensation	(0~100)℃, auto or manual
mV	Measuring range	-1999.9mV ~ 0 ~ 1999.9mV
	Resolution	1 mV	0.1 mV
	Accuracy	±0.1% FS	±0.03% FS
Cond.	Measuring range	/	Conductivity: (0.00~20.00)μS/cm, (20.0~200.0)μS/cm (200~2000)μS/cm, (2.00~20.00)mS/cm (20.0~200.0)mS/cm, (200~2000)mS/cm(K=10) TDS:(0~100)g/L Salinity:(0~100)ppt Resistivity:(0~100)MΩ·cm







	Resolution	/	0.01/0.1/1 μS/cm; 0.01/0.1 mS/cm
	Accuracy	/	Electrode: ±0.5% FS, Meter: 0.8% FS
	Temp.compensationrange	/	(0~100)°C,auto
	Electrode constant	/	0.1/0.5/1/5/10/50/100 cm-1
Temp.	Range	(-10 ~ 110)℃
	Resolution	0.1℃
	Accuracy	±0.5℃
Other	Data Stroage	1000 sets
	Output	USB
	Power	12V/1A
	Ambient Temp.	15 ~ 30 ℃
	Ambient Humidity	≤85%
	Dimensions/N.W.	215×170×37mm/600g
	IP grade	IP54
	Standard Accessaries	pH electrode, Cond. Temperature probe, pH buffer solution (powder-like). Power adapter, Manual, electrode (K=1, matches 01-MP813X)
